GN121 walking tractor are traction drive dual -purpose walking tractor ,this machine is widely used in the rice paddy fields,
GN121
Walking Tractor
Good Description:
GN121 walking tractor are traction drive dual -purpose walking tractor ,this machine is widely used in the rice paddy fields,
upland plains, mountainous and hilly areas, coupled with the corresponding farm machinery for plowing rotary tillage harrowing ,planting ,harvesting ,pumping ,transportation, spraying pesticides and so on.
For this model can work with independent seat assembly when rotary land or plow land or other work.
The tractor was created with the expectation of a European market, passed laboratory tests and certification in the
European Union.
The six-speed forward and reverse MSD200 gearbox, the 2020 novelty, was designed for tractors weighing over a ton in
order to withstand the extreme loads that the ZS1100N single-cylinder power engine can deliver
Parameters:
MODEL | GN121 | |
Overall dimensions:(L*W*H) | 2950*980*1240mm | |
Wheel tread | 570,630,690,750,810mm | |
Tyres | 6.00-12 | |
Ground clearance | 210mm | |
Working weight (with rotary tiller) | 500kg | |
Speed Forward | 1.39, 2.47, 4.15, 5.14, 9.12, 15.30 | |
(km/h) Reverse | 1.10, 4.10 | |
Turning speed | Low:199; High:250 | |
Rotary tiller | Width | 600mm |
Number of blades | 18pcs | |
Model | S195N | |
Type | Single cylinder,4-stroke,horixontal,water-cooled,diesel | |
Cooling mode | Condenser (Radiator) | |
Rated power | 9.7kw | |
Engine | Rated speed | 2000rpm |
Fuel efficiency: | ≤244.8gl/kw.hr | |
Net weight | 150kg | |
Main farm implements | 1)Anti-skid steel wheel; | |
2)Double-plough (optional) | ||
3)Trailer(optional) | ||
Packing | Case dimensions | 116*108*108cm |
N.W/G.W.: | 500/540KG | |
Conveyance: | Qty/20' FCL.: | 20pcs |
Qty/40'(HQ) FCL.: | 40pcs(packing mud wheel inside box) 48pcs(mud wheels | |
