The Mingsin Brand 8hp power tiller is of dual-function type that can be used as a means of traction as well as drive. It is featured by its simple and compact structure, good reliability, long service life, easy operation, ample output, light weight and good cross-country ability.

Key words:

MX81

Category:

Walking Tractor

E-mail:

sales@mingsin.com

Message

MX81

Good Description:
The Mingsin Brand 8hp power tiller is of dual-function type that can be used as a means of traction as well as drive. It is featured by its simple and compact structure, good reliability, long service life, easy operation, ample output, light weight and good cross-country ability. MX81 walking tractor is more powerful and efficient than MX61. And the gear-box is in horizontal type which may lead to better equilibrium ratio. It is very suitable for use in paddy fields, dry fields, orchards, vegetable gardens and hilly land with a little inclination.
It can be used for plowing, rotary tilling, harrowing in paddy fields, harvesting, drilling, ditching, transportation and etc. if suitable farm implements or accessories are attached. In addition, it can also be extensively used as a stationary power source for small scale drainage and irrigation, sprinkling, grain threshing, cotton ginning, flour milling, fodder cutting and so on.

Parameters:

Model		Unit	MX81
Structure weight	Without rotavator	kg	205
	With rotavator		262
Working weight (with rotavator)		kg	274
Overall dimensions (LxWxH)		mm	2170x845x1150
Number of blades		PCS	14-20
Rototilling width		mm	700, 800, 900, 1000
Type of tractor			Single axle, dual-purpose for both traction & drive
Travelling speed	Forward	Km/h	1.98, 3.08, 4.98, 8.04, 12.49, 20.2
	Reverse		1.53, 6.18
Type size			6.00-12
Wheel track		mm	680~740(adjustable)
Min. ground clearance		mm	210
Min. turning radius		m	0.71 (without rotavator)
Model of engine			R180AN
Type of engine			Horizontal 4-stroke
Bore x stroke		mm	80*80
Total displacement		L	0.402
Compression ratio			22±1
Turing speed of crankshaft		rpm	2600
1-hour rated output		KW/hp	5.67/8
12-hour rated output		KW/hp	5.15/7
Specific fuel consumption		g/kw.h	≤278.8
Specific lube oil consumption		g/kw.h	≤2.72
Cooling mode			Condenser (Radiator)
Main farm implements (optional)			Anti-skid steel wheel Model 100-640 Single-furrow plough Model 1LS-125 Turnover plough Rotary tiller Model MX80D-1 Sprinkler Model 50BPZ-45 reaper Model 4GL-100 Trailer 7C-0.8 (Standard)
