TS650-TS654 Tractor

Our smooth-shifting, fully synchronized transmission with 16 forward gears and 8 reverse gears could provide you amazing efficiency. With the high range for travel speed, medium range for mowing and low range for hard-pull applications and loader work, provide you the power you need for the task at hand. That means you`ll always be able to make a proper gear selection in a wide speed range according to the changes of circumstances, the function of different farm implements, the changing of speed.

Key words:

TS650-TS654 Tractor

Category:

Tractor

Message
TS650-TS654 Tractor

Main Features:
■ Smooth shifting performance
Our smooth-shifting, fully synchronized transmission with 16 forward gears and 8 reverse gears could provide you amazing efficiency. With the high range for travel speed, medium range for mowing and low range for hard-pull applications and loader work, provide you the power you need for the task at hand. That means you`ll always be able to make a proper gear selection in a wide speed range according to the changes of circumstances, the function of different farm implements, the changing of speed.
You can also choose to install the crawling gear structure which could double the number of the gears and provide you better traction when you have tougher tasks.
■ Tilting traction structure
Tilting traction structure effectively reduces the impact load and tractor vibration, the driving experience is more comfortable while making the connection structure more durable.
Full Vision cab with frameless glass cover, provides maximum field of vision for you, making it safer to operate the tractor.
Using plastic strips to seal the whole cab, which could effectively cut off the noise from external environment, gives you an excellent sealing performance.
The operator-oriented designing idea and ergonomic interior layout, make every button in the cab around you clearly marked and easy to touch. Equipped with heater, you can choose to install air conditioning get a more comfortable and pleasant driving experience.
Mechanical hydraulic seat with armrests and headrest could provide you an adequate support. That means it could provide you complete comfort and confidence by effectively reducing turbulence generated during operation when you operate in the toughest of territory.
■ Hydraulic output
Hydraulic output is optional, making your tractor match more kinds of farm machinery and implements, to meet your different demands.
Paddy wheel is optional, making it adapt to different working conditions


Technical Specifications:

Model

TS800 Tractor

TS804 Tractor

Drive Type

4×2

4×4

Engine



Engine Manufacturer

YTO Group Corporation

YTO Group Corporation

Engine Model

LR4B5-23

LR4B5-23

Engine Type

vertical,water-cooled,four-stroke,direct injection

vertical,water-cooled,four-stroke,direct injection

Max Torque(N·m)/Revolving Speed(rpm)

≥330/1700

≥330/1700

Displacement(L)

4.95

4.95

Cylinder Diameter * Stroke

108×135

108×135

Fuel Tank Capacity(L)

150

150

Engine Rated Power (kW/rpm)

59

59

Rated Operating Conditions Fuel Consumption Rate(g/kW·h)

≤242

≤242

Drive Train



Clutch

dry,single disc,independent dual-stage

dry,single disc,independent dual-stage

Standard PTO speed(rpm)

(760,1000)/(540,1000)

(760,1000)/(540,1000)

Gears

8F+4R/16F+8R(creeper)

8F+4R/16F+8R(creeper)

Steering type

hydraulic steering

hydraulic steering

Gear Shift Mode

meshing gear shift

meshing gear shift

Speed Range(Km/h)

0.41~31.11

0.46~34.85

Break System



Service Brake

pedal,mechanical drive,hydrostatic,disc

pedal,mechanical drive,hydrostatic,disc

Parking Brake

handle operation,
multi friction surface mechanical compress,
oil bath type

handle operation,
multi friction surface mechanical compress,
oil bath type

Hydraulic System



Hydraulic Output Flow(L/min)

50

50

Hydraulic Output Valve

2 ways

2 ways

Working Device



Three-Point Suspension

postposition,Category Ⅱ

postposition,Category Ⅱ

Max.Lifting Capacity(kN)

14.2

14.2

Tillage Depth Adjustment

draft and position adjustable,floating control

draft and position adjustable,floating control

General Parameter



Overall Dimension(L×W×H)mm

With cab

4027×2050×2670

4027×2050×2750

Without cab

4027×2050×2670

4027×2050×2750

Wheelbase(mm)


2210

2195

Min. operating weight(kg)

With cab

3600

3873

Without cab

3350

3683

Min. Ground Clearance(mm)


418

375

Min.turning radius(mm)

3400

4200

Front Tire

6.5-20

11.2-24

Rear Tire

14.9-30

16.9-34

Rated Pull

15.5

18.6

Optional Disposition

  hydraulic pressure lifter,
air brake,
swing draw bar,
creeper gear,
paddy tire,
2 group hydraulic output

  hydraulic pressure lifter,
air brake,
swing draw bar,
creeper gear,
paddy tire,
2 group hydraulic output
