Wheat Seeder-Multirows

The multi-row seeder can be coupled to all cultivators or walking tractor. This product is the perfect choice for sowing small and medium fields, being suitable for both straw and legume cultivation. The planting distance between the rows is 35 cm. If you want the rows to be grown at a greater distance, you can remove the row from the middle thus increasing the distance to 70 cm.

Key words:

Wheat Seeder-Multirows

Category:

Seeder

Message
Wheat Seeder-Multirows

GOODS DESCRIPTION:
The multi-row seeder can be coupled to all cultivators or walking tractor. This product is the perfect choice for sowing small and medium fields, being suitable for both straw and legume cultivation. The planting distance between the rows is 35 cm. If you want the rows to be grown at a greater distance, you can remove the row from the middle thus increasing the distance to 70 cm.
The drive wheels are driven by means of a chain over the blocks for distribution of the marks, leaving the seed to fall into the trench prepared by the plough.
The depth to sow is adjusted from the plough. The desired distance between rows can be traced with a marker.
The selection range for the desired distance between plants is made from the seed distribution block.
The product has a hopper for planting seeds with the possibility to select by closing or opening the two flaps, so you can select the module corresponding to the seeds you want to sow.


Parameters:

Model

2BSF-5A

2BSF-5B

2BSF-6A

2BSF-6B

2BSF-7A

2BSF-8A

Overall dimensions

100*98*68cm

100*98*68cm

120*98*68cm

120*98*68cm

135*98*68cm

150*98*68cm

Planting rows

5 rows

6 rows

7 rows

8 rows

Seeding width

950mm

1000mm

1200mm

1200mm

1350mm

1500mm

Matched power

6-20hp walking tractor or Cultivator

Row Spacing

150-250mm

Seeding quantity

75-420kg/hec.

Seeding depth

20-105mm

Sowing box capacity

28 kgs

28kg

34kg

34kg

39kg

45kg

Net Weight

36

45kg

40 kg

50kg

46kg

55kg

Wheel track

450mm

480mm

630mm

630mm

480mm

630mm
