Good Description: 1.It is mainly used for harvesting rice, also suitable for harvesting wheat, with comprehensive economic benefits. 2. Lengthen Threshing Cylinder, Double Threshing Sieves, and the Secondary Thresher are equipped, which make grain cleaner. 3. Strengthen Chassis with min. Ground clearance 275mm, technology of roller seal type are adopted from half feed combine harvester. 4. It adopts Axial Flow Threshing Cylinder, rotating speed and threshing clearance can be adjusted, and thus suit for different crops. 5. New outline, plastic steel awning, and baking finish are to taste of our customers. 6. Mechanical steering system, hydraulic steering system and HST are optional.
Parameters:
Model
4LZ-1.6 Combine Harvester
Dimension
(L*W*H (with canopy) 4350*2100*2550 mm
Weight
2100 KGS
Engine
Model: 4B2-45V32
Type: Water-cooled In-line 4 Stroke
Displacement:(L)2.417
Output (kW/HP/rpm): 33.5/ 45.5 /2600
Fuel Tank Capacity(L ): 48L
Drive System
Crawlers
Track Gauge Rubber lug wheel with thick rim
Width * Ground Contact Length: 380* 1440mm
Average Ground Contact Pressure (kPa): 0.27
Minimum Ground Clearance: 230mm
Transmission Type
HST (Hydro Static Transmission)
Traveling Speed (km/h) 6.36
Steering
Clutch and Brake
Cutting
Pickup Reel Diameter x Width: 600*1200 mm
Height Adjustment: Hydraulics
Gathering length (mm/inch): 1245/49.1
Cutter Bar length(mm/inch): 1450/56 86
Cutting Height Range(mm/inch): -0(0)-800(31.5)
Threshing System Spiked Tooth Axial Flow
Threshing/Separating
Threshing system spiked tooth axial flow
Threshing Cylinder
Diameter x Length (mm/inch): 450/17.8x1320/51.76
Revolutions (rpm): 625
Concave Area (m2): 0.7185
Cleaning
Oscillating 3 Way Air Stream Cleaning System
Electrical Start System
Battery Starting, Lighting equipment, Alarms Electrical System Coolant Temperature, Battery Charge, Engine Oil, Grain Tank Full,Clogging
